Injector nozzle Mitsubishi L2A – L3E | S3L(2) | S4L(2) | S4L | S4S – S6S | S4Q2 | Weidemann | Peljob | Terex | Toro

Description

Technical specifications:

• Opening pressure (setting value): approx. 120 – 130 Bar (12.0 – 13.0 MPa)
• Injector tightening torque: 35 – 40 Nm
• Injector type: Pintle nozzle
• Spray angle: 15°

Exclusive from our own production line: a high-quality injector nozzle that meets the strictest tolerances. This ‘Snelparts‘ nozzle tip has been developed as the superior alternative to standard aftermarket parts.

We guarantee a perfect spray pattern and an exact seal, resulting in a smoother-running engine and cleaner combustion.

advice from experience: don't go for cheaper alternatives. Extensive research has been done into OEM quality like well-known brands in this industry!

Supplied including complete sealing set for direct installation! We supply this nozzle standard with all necessary new copper washers. This allows you to get to work safely and leak-free right away. The included set consists of:

• A new heat shield (fire washer) against extreme heat and soot buildup.

• A copper seal for the injector for 100% compression retention.

• A leak-off line seal to prevent fuel leakage.

suitable for the models below:

mitsubishi engines

• L2E, L3E S3L, S3L2, S4L, S4L2 S3Q2, S4Q2 S4S, S4S-DT (Turbo), S6S

Mitsubishi

• L2E, L3A, L3C, L3E
• S3L, S3L2, S4L, S4L2
• S4Q2
• S4S, S6S

OEM for reference:

• MD603660, 093400-05060, DN15PD6
• Nozzle: DN15PD6.

The matching models:

ami

• GS 0009 M 32S, GS 0011M32S, GS0006M32S

atlas

• AM15R, AM16R, AM21R, AM29R, AM35R

bobcat

• X119

casalini

• M10

case

• CX15B Series 2, CX17B ZTS, CX18B Series 2

caterpillar

• 302.5C, 303CR, 303SR, DP15N, DP18N, DP20CN

daewoo doosan

• SOLAR 015+, SOLAR 015 PLUS, SOLAR 018 VT

deutz

• Agrokid 30, Agrokid 40, Agrokid 50

eurocomach

• ES 150.3, ES 180.3

hanix

• H22A, H22B, H24A, H26C, H36C, H36CR

hyundai

• R15-7, R16-7, R16-9, R22-7, R25Z-9A, R27Z-9, Robex 15-7, Robex 16-7, Robex 22-7, Robex 28-7, Robex 35-7, Robex 36N-7, Robex 55-7

iseki

• TU125, TU127, TU135, TU137

kobelco

• SK70SR, SK70SR-3

lamborghini

• R1.30, R1.40, R1.50

mitsubishi

• 410DTC, 4320, 4340, 450, 450DTC, 470DTC, 4920, 4940, F16C, F16D, FD15-MC, GF14, GF15, GF130PYS1W, GO26 t/m GO341

• GS160, GS180, GS182, GS200, GS210, GS230, GS250, LG2943, MM20, MM20CR, MM20SR, MM20T, MM25T, MM30CR, MM30SR, MM30T, MM35T, MM40CR, MM40SR

• MT14, MT15, MT16, MT17D, MT155, MT156, MT165, MT1600, MT1800, MT200 t/m MT341

• MX15, TU42D, TU42DX, TU73D, TU73E, TU73EX, VMS16, VMS16G

mitsubishi engine

• L3C, L3E, S3L, S3L2, S3Q2, S4L, S4L2, S4Q, S4Q2, S4S, S6S

new holland

• E16, E16B, E16 Evolution, E18, E18B, E18 SR, E18 Evolution, EC15, EC25, EC35

pel job

• EB10, EB12.4, EB14.4, EB16.4, EB25.4, EB30.4, EB150, EB200, EB250, EB306, ED750, Sirius

terex / schaeff

• HR3.7, HR14, HR16, HR16A, TC16, TC20, TC25, TC29, TC35, TC37, TC51, TC65

toro

• GM 220D, GM 223D, Groundsmaster 220-D, Groundsmaster 223-D, Groundsmaster 323-D, Groundsmaster 324-D, Reelmaster 220-D, Reelmaster 223-D, Reelmaster 5100-D, Reelmaster 5300-D, Workman 3300-D, Workman 4300-D

volvo

• EC13 XR, EC13 XTV, EC14, EC15 XT, EC15 XTV, EC15B XR, EC15B XT, EC25, EC30, EC35, EX15 XR

weidemann

• 811D/M, 911D/M, 1010D/M, 1050D/M, 1055D/M, 1070D/M, 1504D/M
