V-belt Iseki TX/TF & Satoh ST1510 | 863 x 9,7 x 8 mm

Description

This V-belt with designation 863 x 9.7 x 8 mm is a narrow profile belt for small compact tractors from Iseki, Bolens, Mitsubishi and Satoh among others. The belt transfers power from the engine pulley to the driven pulley. Replace it if you see fraying, cracks or slipping.

✔️ Exact fit for the OEM version, main number 5663-011-351-00
✔️ Narrow profile 9.7 x 8 mm with a length of 863 mm
✔️ Broadly applicable across four brands, from the Iseki TX and TF models to Satoh ST1510 and S370

Dimensions

• Designation: 863 x 9.7 x 8 mm
• Profile: narrow profile, 9.7 x 8 mm
• Length: 863 mm

Note the length type: Li is the inside circumference, Lw/Ld the pitch length and La the outside circumference. Not sure? Measure the old belt or order by OEM number.

Fits:

Iseki

• TX1300, TX1500, SIAL15, SIAL17, SIAL193
• TF15, TF17, TF19, TF193, TM223
• SG15, 2115, SF200

Bolens

• G152, G154, G172, G174

Mitsubishi

• KE70, KE75, MT372

Satoh

• ST1510, S370

OEM for reference:

• 5663-011-351-00, 566301135100
• 6213-671-003-00, 621367100300
• 621367100210
• MD011351
• MD030-768
